Triangle Tube Instinct Combi 199 Condensing Boiler, 159,000 BTU

Triangle Tube Instinct Combi 199 Condensing Boiler, 159,000 BTU

Combi 199

Technical Specifications:

  • Input Modulation (BTU): 24,875 - 199,000
  • DOE Rating (BTU): 184,000
  • Net AHRI Rating (BTU): 159,000
  • Efficiency (AFUE): 95%
  • Turndown (Modulation) Ratio: 8 : 1
  • Fuel Type: Natural Gas (NG) or Propane (LP)
  • Boiler Connections: 1" NPT
  • Gas Connection: 3/4" NPT
  • Gas Supply Pressure: 5-13" WC (natural gas), 8-13" WC (propane)
  • Max. Operating Pressure: 50 psi (heating system) / 150 psi (DHW system)
  • DHW Connection: 3/4" NPT
  • DHW Min Flow Rate: 0.5 GPM
  • DHW Output: 5.3 GPM @ 70F Rise; 4.9 GPM @ 75F Rise; 4.6 GPM @ 80F Rise
  • Vent/Air Size: 3"
  • Vent Material: PVC, CPVC, PolyPropylene, St. Steel
  • Power Supply: 120V, 60Hz
  • Dimensions (Depth x Width x Height): 16-1/2" x 21-3/4" x 33"
  • Weight (lbs): 130
  • Water Volume (Gallons): 4
  • Mounting Type: Wall-mounted (Wall-hung).




Features:



  • 2-in-1 Combi Boiler with Space-Heating & DHW (Domestic Hot Water) functionality
  • Stainless steel heat exchanger
  • Energy Star listed
  • Cascade functionality (up to 6 boilers)
  • Built-in freeze protection
  • Compatible with PVC, CPVC, PP and Stainless Steel vent pipe
  • Includes propane conversion kit
Product Specs
Net BTU Rating 150,000 - 175,000
Boiler Type Combi
Mounting Type Wall-Hung
Vent Material PP;PVC;CPVC;Cat III St. Steel
Venting Size 3"
