Honeywell Q313B1005 35" Thermopile, 750 mV

Honeywell Q313B1005 35" Thermopile, 750 mV
Honeywell Q313B1005 35" Thermopile, 750 mV QR Code
QR-Code
Views: 5548 Model: Q313B1005
UPC: 85267066358

MPN: Q313B1005

Weight:3.00 oz

Dimensions (L x W x H ): 5.00 x 3.00 x 0.50

Usually ships: Upon availability
$40.95
Qty: Add to Cart

ORDERS OVER $99 SHIP FREE

Have any questions?
Contact us at 1-800-246-9552

The Q313B1005 from Honeywell is a 750 mV Thermopile w/ Terminal Block, 35”. It contains multiple thermocouples connected in series to increase the millivoltage output. The power generated is sufficient to operate an automatic millivolt gas control system, independent of any outside power source.


Features:

  • Push-in clip, split nut, and adapter assembly for easy pilot burner installation;
  • Spade or quick-connect terminals available for millivolt gas control connections.

Technical Specifications:

  • Application: Thermopile;
  • Includes: Junction box for series hookup w/ high limit switch, 1/2" thermopile attaching nut;
  • Used With: Q314, Q324, Q327, Q377, Q379, Q382 Pilot Burners;
  • Temperature Ratings: 1400°F (760°C) (hot junction); 780°F (416°C) (cold junction);
  • Voltage: 750 mV, 600 mV to 750 mV (open circuit output);
  • Connection Type: Spade Terminals;
  • Resistance: 2.89 ohms;
  • Lead Length: 35" (889mm).
Product Specs
Accessory For: Q314 Pilot Burner
Connection Type: Spade Terminals
Type: Thermopile
Voltage: 750mV
