306P, 6-Zone Switching Relay w/ Priority, Expandable

306P, 6-Zone Switching Relay w/ Priority, Expandable
Click Image for Gallery
306P, 6-Zone Switching Relay w/ Priority, Expandable 306P, 6-Zone Switching Relay w/ Priority, Expandable
306P, 6-Zone Switching Relay w/ Priority, Expandable QR Code
QR Views: 1586 Model: 306P


Availability:8

Weight:4.69 lb

Dimensions (L x W x H ): 11.50 x 8.50 x 3.00

Usually ships: 1 business days
$228.95
Qty: Add to Cart
Add to Wish List Add to Compare

ORDERS OVER $99 SHIP FREE

Have any questions?
Contact us at 1-800-246-9552

Switching Relay Six Zones with Priority
  • Zones: 6
  • Control: Microprocessor Control
  • Power supply: 115 VAC, 60 Hz, 17.3 A
  • Transformer Rating: 40 VA at 24 VAC
  • Control load: 7 VA at 24 VAC
  • Fuses: T5A, 250 V slow blow glass fuse, two spare fuses included
  • Pump relays: 115 VAC, 5 A, 1/3 HP, 17.3 A combined
  • Boiler XX end switch: 24 VAC, 5 A
  • DHW end switch: 24 VAC, 5 A
  • Mod boiler output: 0-10 V 500 ohm min load impedance, 4-20 mA 1 k ohm max load impedance
  • Materials: ABS Plastic (Cover), Galvanized Steel (Base) NEMA type 1
  • Dimensions: 8-3/16" x 10-12/18" x 2-3/8"
  • Packaged weight: 5 lbs

3-year warranty
