008 Circulator Pump, 1/25 HP, 115V

008 Circulator Pump, 1/25 HP, 115V
008 Circulator Pump, 1/25 HP, 115V QR Code
QR-Code
Views: 3555 Model: 008-F6
UPC: 687752190434

MPN: 008-F6

Availability:5

Weight:8.00 lb

Dimensions (L x W x H ): 9.00 x 7.00 x 7.00

Usually ships: 1 business days
$196.95
Qty: Add to Cart

ORDERS OVER $99 SHIP FREE

Have any questions?
Contact us at 1-800-246-9552

The 008-F6 from Taco is a Cast Iron Circulator Pump, 1/25HP, 115V. It's specially designed for use in higher-head applications, such as hydronic heating, radiant heating and solar heating. A typical application for the Taco 008 circulator is in conjunction with a radiant heat manifold in mixing stations and radiant panels. This model features a unique, field-serviceable cartridge that contains all moving parts. Taco 008-F6 Circulator Pump is compact, direct-drive, has low power consumption and is ideal for high-efficiency jobs.


Taco 008-F6 replaces:
Grundfos UP15-42F/R, UPS15-58FC spd 2
Armstrong Astro30 and
Wilo Star 16.


Applications:

  •  Hydronic Heating/Cooling
  •  Radiant Heating
  •  Zoning with Pumps
  •  Mixing Stations
  •  Hydro-Air Fan Coils
  •  And others.


Electrical Data:

  • Voltage: 115V;
  • Hertz: 60Hz;
  • Phase: 1;
  • Amps: 0.79A;
  • HP: 1/25HP;


Technical Specifications:

  • Flow Range: 0 – 14 GPM;
  • Head Range: 0 – 16 Feet;
  • Minimum Fluid Temperature: 40˚F (4˚C);
  • Maximum Fluid Temperature: 240°F (115˚C);
  • Maximum Working Pressure: 125 psi;
  • Connection Sizes: 3/4", 1", 1-1/4", 1-1/2" Flanged.


Warranty:

  • 3 year manufacturer's warranty.
Product Specs
Amperage:0.79
Application:Heating
Connection Size:3/4"
Connection Type:Flanged
Flow Range (GPM):0-14
Head Range (ft.):0-16
Hertz:60
Horse Power:1/25
Material:Cast Iron
Max Flow (GPM):14
Max Head (Ft):16
Max Pressure (PSI):125
Phase:1
RPM:3250
Temperature Range (F):40° to 230°F
Type:Pump
Voltage:115v
Warranty:3-Year Warranty
