005 Circulator Pump, 1/35 HP, 115V

005 Circulator Pump, 1/35 HP, 115V
005 Circulator Pump, 1/35 HP, 115V QR Code
QR-Code
Views: 3836 Model: 005-F2
UPC: 687752001082

MPN: 005-F2

Weight:8.00 lb

Dimensions (L x W x H ): 9.00 x 7.00 x 7.00

Usually ships: Upon availability
$82.95
Qty: Add to Cart

ORDERS OVER $99 SHIP FREE

Have any questions?
Contact us at 1-800-246-9552

The 005-F2 from Taco is a Cast Iron Circulator Pump, 1/35HP, 115V. It's designed for a wide range of residential and light commercial water circulating applications. It features a unique replaceable cartridge which allows field-service, and saves the need for replacing the entire circulator. Typical applications for this model are zoning with pumps, adding a zone and fan coil installation. Taco 005 Circulator Pump is compact, direct-drive, has low power consumption and is ideal for high efficiency jobs.

Taco 005-F2 replaces Grundfos model UPS15-58FC @ spd 3.


Applications:

  • Hydronic Heating/Cooling;
  • Radiant Heating;
  • Zoning with Pumps;
  • Hydro-Air Fan Coils;
  • And others.


Electrical Data:

  • Voltage: 115V;
  • Hertz: 60Hz;
  • Phase: 1;
  • Amps: 0.52A;
  • HP: 1/35HP;


Technical Specifications:

  • Flow Range: 0 – 19 GPM;
  • Head Range: 0 – 9 Feet;
  • Minimum Fluid Temperature: 40°F (4°C);
  • Maximum Fluid Temperature, Cast Iron: 230°F (110°C);
  • Maximum Working Pressure: 125 psi;
  • Connection Sizes: 3/4", 1", 1-1/4", 1-1/2" Flanged.


Warranty:

  • 3 year manufacturer's warranty.
Product Specs
Amperage: 0.52
Application: Heating
Connection Size: 3/4"
Connection Type: Flanged
Flow Range (GPM): 0-19
Head Range (ft.): 0-9
Hertz: 60
Horse Power: 1/35
Material: Cast Iron
Max Flow (GPM): 19
Max Head (Ft): 9
Max Pressure (PSI): 125
Phase: 1
RPM: 3250
Temperature Range (F): 40° to 230°F
Type: Pump
Voltage: 115v
Warranty: 3-Year Warranty
