Stiebel Eltron DHC 10-2, Electric Tankless Water Heater, 9.6/7.2kW, 240/208V
Click Image for Gallery
A step above typical POU (Point-Of-Use) water heaters, DHC Classic series offers a better heating element design and incorporates an internal flow adjustment screw, which allows to fine-tune the hot water temperature as needed. Compact and elegant, can be installed installed inside the cabinet or out. DHC 10-2 Classic is the most powerful model in the DHC series, and will provide a 80°F+ temperature increase at 0.8 GPM, 65°F at 1.0 GPM or ~52°F at 1.25 GPM. Important: this model does not come with a flow restrictor or an aerator and has a minimum activation flow rate of 0.8 GPM - be sure determine your fixture flow rate and groundwater temperature prior to purchasing to ensure proper performance. DHC 10-2 Classic is well suited for all US regions and output hot water temperature would vary depending on fixture flow.
Technical Specifications:
Features:
Technical Specifications:
- Voltage: 240 or 208V (hardwired)
- Output: 9.6kW at 240V (7.2kW at 208V)
- Amperage: 40A at 240V (35A at 208V)
- Min. recommended wire size: 8/2 AWG
- Min. recommended curcuit breaker size: 40A at 240V (35A at 208V)
- Water Connections: 1/2" Male NPT
- Min. activation flow rate: 0.79 gpm
- Nominal water volume: 0.13 gal
- Max. operating pressure: 150 psi
- Tested to pressure: 300 psi
- Dimensions (Height x Width x Depth): 14-3/16" x 7-7/8" x 4-1/8"
- Weight: 5.3 lb
Features:
- Manually adjustable hot water flow (via internal screw) - allows to fine-tune the amount of water flowing through the water heater to achieve desired temperature
- Superior reliability, built-in dry-fire and failure protection, high limit safety switch
- No PRV''s, expansion tanks or circulating valves needed
- No standby heat losses
- Perfect for single-fixture applications in both residential and commercial settings
- Made in Germany
