1/2" Female Sweat Copper Stub Out Elbow w/ Ear, 3.5" x 8"

1/2" Female Sweat Copper Stub Out Elbow w/ Ear, 3.5" x 8"

Solid copper stub-out elbow 3.5" x 8" long, with 1/2" female sweat inlet and spin closed outlet. Square mounting strap w/ holes allows to secure the stub out to wooden and metal surfaces for added support. Copper pipe size is 1/2" (5/8" OD), suitable for connecting 1/2" sweat or 5/8" OD compression outlet valves. Spin closed outlet simplifies pressure testing and prevents dirt and debris from getting inside the pipes during construction.

Technical Specifications:

  • Height (part w/ PEX outlet): 3.5"
  • Stub-out length: 8"
  • Inlet: 1/2" female sweat (accepts 1/2" copper pipe)
  • Copper pipe size: 1/2"




Features:



  • Made from lead-free, 100% copper and approved for potable water use
  • One-piece body design
  • Drop ear (square nailing plate) with holes allows to secure stub-out to wooden or metal surfaces
  • Saves time, installation costs and labor
  • Spin closed outlet for easy pressure-testing
  • Manufactured in the USA
Product Specs
Connection Sweat
Options Flange/Ear
Size1 1/2"

Write a review

Please login or register to review
  • Views: 1232
  • Model: 609-L248E
  • MPN: 609-L248E
  • Availability: In Stock
  • Usually ships: Upon availability
  • $ 4.20
