Magnetic Drive Pump for Highly Corrosive, 1/25HP, 115V

Magnetic Drive Pump for Highly Corrosive, 1/25HP, 115V

The 578603 from Little Giant is a Magnetic Drive Pump for Highly Corrosive, 1/25HP, 115V. Designed for in-line, non-submersed use.

The Little Giant 2-MD-HC has 6ft power cord with 3-Prong Plug, leakproof, seal-less magnetic drives, 99.5% pure alumina ceramic shaft and thrust washers for excellent wear and trouble-free service. Features 1/2" FNPT Intake and 1/2" MNPT Discharge. Thermally protected open fan-cooled motor has ball bearings.


Features:

  • Run-dry capability up to 8 hours;
  • Specific Gravity up to 1.1;
  • Thermally protected, open, fan-cooled motor;
  • 6' power cord with 3-prong plug;
  • Sleeve bearings;
  • Ambient Air Temperature up to 77F;
  • Fluid Temperature up to 200F.


Technical Specifications:

  • Horsepower: 1/25HP;
  • Flow: 500 @ 1' of Head;
  • Cord Length: 6';
  • Shut Off Head: 16.2';
  • Voltage: 115V;
  • Intake: 1/2" FNPT;
  • Discharge: 1/2" MNPT;
  • Hertz: 50/60Hz;
  • Watts: 94W;
  • Weight: 6.5 lbs;
  • Height: 5.5";
  • Width: 3.9";
  • Length: 7.9";
  • Certification: UR/C-CSA.


Warranty:

  • 1 year manufacturer's warranty.



Product Specs
Amperage: 1.3
Application Strong Acids
Capacity (Gallons): 8.5
Cord Length: 6 Feet
Dimensions: 5.5"H x 3.9"W x 7.9"L
Flow at 1 FT Head: 500 GPH
Hertz: 50/60
Horse Power: 1/25
RPM: 3100
Shutoff Head (ft.): 16.2'
Voltage 115v
Wattage: 94
Weight (lbs): 8.75 lbs

Write a review

Please login or register to review
  • Views: 7524
  • Magnetic Drive Pump for Highly Corrosive, 1/25HP, 115V QR Code
    QR
  • Model: 578603
  • MPN: 578603
  • Availability: Discontinued
  • $ 196.95
