Little Giant Automatic Condensate Removal Pump w/ Safety Switch, Tubing, 6' Cord, 1/30HP, 115V

Little Giant Automatic Condensate Removal Pump w/ Safety Switch, Tubing, 6' Cord, 1/30HP, 115V

Little Giant Automatic Condensate Removal Pump w/ Safety Switch, Tubing, 6' Cord, 1/30HP, 115V QR Code
QR-Code
Product Code: 554435 UPC: 010121544352

Availability: In Stock

Weight:6.00 lb

Dimensions (L x W x H ): 13.00 x 8.00 x 6.00

Usually ships: 1 business days
$46.95

* Country:
* State:
* ZIP:
Qty: Add to Cart

Have any questions?
Contact us at 1-800-246-9552

The 554435 from Little Giant is an Automatic Condensate Pump w/ Safety Switch, Tubing and 6' cord, 1/30HP, 115V. It includes 20ft of 3/8" ID tubing and Safety Switch that can be connected to shut down the air conditioner condenser or wired to an alarm to warn of possible tank overflow.
Little Giant condensate pumps VCMA Series are the new generation fully automatic vertical-type condensate removal pumps with 1/2 gallon leakproof, rustproof, ABS tank with mounting tabs, capacity, stainless steel motor shaft, and removable 3/8" O.D. Barbed check valve. With thermally protected motor the Little Giant VCMA-20ULST Condensate Pump is UL/CSA listed and suitable for high-efficiency gas furnace applications that produce an acidic condensate.


Head (ft) Flow (GPH) Head (m) Flow (LPH)
1 80 0.3 302.8
5 70 1.5 265.0
9 55 2.7 208.2
15 25 4.6 94.6


Features:
  • Includes 20' of 3/8 ID tubing;
  • Includes Safety switch;
  • 1/30 HP high performance motor;
  • 6' power cord;
  • High-impact ABS volute;
  • 1/2 gallon capacity;
  • Stainless steel motor shaft;
  • Snap-action switch;
  • Removable 3/8 barbed check valve;
  • 3 inlet drain holes;
  • Thermal overload protection;
  • UL / CSA listed;


Technical Specifications:
  • Model Number: VCMA-20ULST;
  • Horsepower: 1/30HP;
  • Flow: 80 GPH @ 1' of Head;
  • Cord Length: 6';
  • Shut Off: 20';
  • Intermittent Liquid Temp.: up to 120F;
  • Voltage: 115V;
  • Hertz: 60Hz;
  • Amps: 1.5A;
  • Watts: 93W;
  • Weight: 6 lbs;
  • Height: 7";
  • Widht: 5";
  • Length: 11";
  • Certification: UL/CSA;


Warranty:
  • 2 years from the date of installation.
Product Specs
Flow at 1 FT Head:80 GPH
Horse Power:1/30
Includes:Safety Switch
Shutoff Head (ft.):20'
Voltage:115v
