Grundfos 59896771 Stainless Steel Circulator Pump, 1/8HP, 115V

Grundfos 59896771 Stainless Steel Circulator Pump, 1/8HP, 115V

The 59896771 from Grundfos is a UP15-29SF Stainless Steel, Flanged Circulator Pump, 1/8HP, 115V. This item is mostly used in open loop heating systems, like radiant, hot water recirculation, solar as well as chilled water cooling and other.

Features:

  • Built-in motor protection for longer life;
  • Stainless Steel circulator body;
  • UL/CSA listed
  • Includes (2) Gaskets;


Technical Specifications:

  • Voltage: 115V;
  • Amperage: 0.75 Amps;
  • Hertz: 60 Hz;
  • Phase: 1;
  • Watts: 87W;
  • Max Pressure: 145 psi;
  • Max Temperature: 230F;
  • Min Temperature: 36F;
  • Flow Range: 0-20.5 GPM;
  • Head Range: 0-9.7 ft;
  • Horse Power: 1/8HP;
  • Body: Stainless Steel;
  • Connections: Flanged, 3/4", 1", 1-1/4";


Manufacturer's warranty:

  • 2 years from date of installation.
Product Specs
Application Heating
Connection Type Flanged
Flow Range (GPM): 0-20.7
Head Range (ft.): 0-9.84
Hertz: 60
Horse Power: 1/12
Material1 Stainless Steel
Max Flow (GPM): 20.7
Max Head (Ft): 9.84
Type1 1-Speed Pump
Voltage 115v
