Grundfos 59896771 Stainless Steel Circulator Pump, 1/8HP, 115V

Click Image for Gallery

The 59896771 from Grundfos is a UP15-29SF Stainless Steel, Flanged Circulator Pump, 1/8HP, 115V. This item is mostly used in open loop heating systems, like radiant, hot water recirculation, solar as well as chilled water cooling and other.

Features:

Built-in motor protection for longer life;
Stainless Steel circulator body;
UL/CSA listed
Includes (2) Gaskets;

Technical Specifications:

Voltage: 115V;
Amperage: 0.75 Amps;
Hertz: 60 Hz;
Phase: 1;
Watts: 87W;
Max Pressure: 145 psi;
Max Temperature: 230F;
Min Temperature: 36F;
Flow Range: 0-20.5 GPM;
Head Range: 0-9.7 ft;
Horse Power: 1/8HP;
Body: Stainless Steel;
Connections: Flanged, 3/4", 1", 1-1/4";

Manufacturer's warranty:

2 years from date of installation.

Product Specs
Application	Heating
Connection Type	Flanged
Flow Range (GPM):	0-20.7
Head Range (ft.):	0-9.84
Hertz:	60
Horse Power	1/12
Material1	Stainless Steel
Max Flow (GPM):	20.7
Max Head (Ft):	9.84
Type:	1-Speed Pump
Voltage	115v

Views: 8657
Model: 59896771
MPN: 59896771
Availability: In Stock
Usually ships: within 1 business day(s)
