Grundfos 59896772 3-Speed Stainless Steel Circulator Pump, w IFC, 1/6HP, 115V

Click Image for Gallery

The 59896772 from Grundfos is a UPS15-35SFC 3-Speed Circulator Pump, 1/6HP, with stainless steel housing, suitable for a wide range of open loop and closed loop applications, including radiant heating, hydronic heating, solar, hot water recirculation, chilled water cooling and many others. 3 speeds of the Grundfos UPS15-35SFC model allow to adjust pump's parameters to match system requirements and achieve optimal performance.

Features:

Built-in motor protection for longer life;
Check Valve;
Includes (2) Gaskets;

Technical Specifications:

Voltage: 115V;
Amperage at Speed 1: 0.06 Amps;
Amperage at Speed 2: 0.75 Amps;
Amperage at Speed 3: 0.95 Amps;
Hertz: 60 Hz;
Phase: 1;
Watts at Speed 1: 61W;
Watts at Speed 1: 85W;
Watts at Speed 1: 110W;
Max Pressure: 145 psi;
Max Temperature: 165F;
Min Temperature: 36F;
Flow Range: 0-21.5 GPM;
Head Range: 0-12 ft;
Horse Power: 1/6HP;
Body: Stainless Steel;
Connections: Flanged, 3/4", 1", 1-1/4";

Manufacturer's warranty:

2 years from the date of installation.

Product Specs
Application	Heating
Connection Type	Flanged
Horse Power:	3/20
Material1	Stainless Steel
Max Pressure (PSI):	145
Temperature Range (F):	36-165
Voltage	115v
