Highlander 78,000 BTU Hot Water Gas Boiler, Direct or Power Vent, 85% AFUE, Natural Gas
Click Image for Gallery
Note: product title indicates boiler''s Net AHRI (Net IBR) rating
Highlander series boiler is a fan-assisted (Power Vent) type cast iron boiler, which can also be converted to Direct Vent (sealed combustion) using included kit (see product pictures) - no chimney required.
Fan-forced design allows for up to 50ft of vertical or horizontal vent length and utilizes 3", Cat. III (AL29-4C) vent pipe.
Highlander is a cost-attractive, quality boiler with USA-made heat-exchanger and industry-leading, familiar controls (concealed behind easy-access front panel) and is ideally suited for both new installations and renovations where chimney venting is impractical or not possible.
Boiler includes: Direct Vent Installation Kit (optional installation, room combustion air setup also acceptable), Vent Adapter, HydroStat 3200 Control, Honeywell Step-Opening Redundant Gas Valve, Taco 007e Circulator w/ Flanges, Spark Ignition w/ Continuous Retry, Drain Valve, Pressure Relief Valve (Watts or Apollo brand), Temperature & Pressure Gauge and Manifold.
Technical Specifications:
Features:
Highlander series boiler is a fan-assisted (Power Vent) type cast iron boiler, which can also be converted to Direct Vent (sealed combustion) using included kit (see product pictures) - no chimney required.
Fan-forced design allows for up to 50ft of vertical or horizontal vent length and utilizes 3", Cat. III (AL29-4C) vent pipe.
Highlander is a cost-attractive, quality boiler with USA-made heat-exchanger and industry-leading, familiar controls (concealed behind easy-access front panel) and is ideally suited for both new installations and renovations where chimney venting is impractical or not possible.
Boiler includes: Direct Vent Installation Kit (optional installation, room combustion air setup also acceptable), Vent Adapter, HydroStat 3200 Control, Honeywell Step-Opening Redundant Gas Valve, Taco 007e Circulator w/ Flanges, Spark Ignition w/ Continuous Retry, Drain Valve, Pressure Relief Valve (Watts or Apollo brand), Temperature & Pressure Gauge and Manifold.
Technical Specifications:
- Input (BTU): 105,000
- Net AHRI Rating (BTU): 78,000
- DOE Heating Capacity (BTU): 90,000
- Efficiency (AFUE): 85%
- Fuel Type: Natural Gas
- Boiler/System Type: Hot Water (Hydronic) Cast Iron Gas Boiler
- Boiler Connections: 1-1/4" NPT - Supply/Return Connections, 3/4" NPT - Relief Valve, 3/4" NPT - Drain, 1/2" NPT - Gas
- Pressure Specs: 30 psi relief valve setting, 50 psi max. allowed working pressure
- Vent Type: Direct Vent (sealed combustion using outdoor air) or Power Vent (using indoor air for combustion) - includes hardware/functionality for using either option
- Vent Pipe Size: 3" (Cat III, AL29-4C vent pipe - any brand)
- Internal Water Volume: 3 Gallons
- Dimensions: 15-1/2" Wide x 27" Deep x 38" High
- Weight: 310 lbs (approx shipping weight)
Features:
- Includes parts for Direct Vent (sealed combustion using outdoor air) or Power Vent (using indoor combustion air) installation - no chimney needed
- Premium-level controls: Honeywell/Resideo S8610 & Hydrolevel HydroStat 3200
- Honeywell/Resideo gas valve
- Taco 007e high efficiency ECM circulator included (with flanges)
- Stainless steel precision burners
- Powder coated steel jacket with heavy-gauge, 1" base insulation
- Assembled in Pennsylvania with USA-made components, including robust, time-tested and efficient cast iron heat exchanger with metal section connections for increased boiler life
| Product Specs | |
| Boiler Sections | 3 |
| Boiler Vent Type | Direct Vent |
| Input BTU Rating | 100,000 - 125,000 |
| Net BTU Rating | 75,000 - 100,000 |
| Efficiency (AFUE) | 85% |
| Product Type | Cast Iron Gas Boilers |
| Venting Size | 3" |
- Views: 770
-
- Model: HLR-4-105NT
- MPN: HLR-4-105NT
- Availability: In Stock
- Usually ships: within 1 business day(s)
- $ 2 450.00
