UPS26-99BFC 3-Speed Stainless Steel Circulator Pump, 1/6 HP, 115 volt

Click Image for Gallery

The 98961763 from Grundfos is a UPS26-99SFC 3-Speed Circulator pump. This model incorporates a three speed motor for increased versatility, a built-in check valve and a stainless steel housing for enhanced corrosion resistance. The wet rotor design allows it to be virtually silent while operating, while built-in motor protection assures long life of the circulator. Performance parameters (flow rates and pressure drop) of the Grundfos UPS26-99SFC model make it well suited for a wide range of applications.

Applications: used in both closed and open loop systems, hydronic and fan coil heating, hot water recirculation systems, solar heating, radiant heating systems, and many others

Features:

Built-in motor protection for longer life and better performance;
Whisper-quiet operation for sound sensitive installations;
Stainless Steel body;
Includes (2) Gaskets (O-rings);
UL/CSA listed.

Technical Specifications:

Voltage: 115V;
Amperage at Speed 1: 1.3 Amps;
Amperage at Speed 2: 1.5 Amps;
Amperage at Speed 3: 1.8 Amps;
Hertz: 60 Hz;
Phase: 1;
Watts at Speed 1: 150W;
Watts at Speed 2: 179W;
Watts at Speed 3: 197W;
Max Pressure: 145 psi;
Max Temperature: 230°F;
Min Temperature: 36°F;
Flow Range: 0-33 GPM;
Head Range: 0-29 ft;
Horse Power: 1/6HP;
Body: Stainless Steel;
Connections: Flanged 1/2", 3/4", 1”, 1-1/4”.

Warranty:

2 years from the date of installation.

Product Specs
Application	Heating
Connection Size:	3/4"
Connection Type	Flanged
Flow Range (GPM):	0-33
Head Range (ft.):	0-29
Hertz:	60
Horse Power	1/6
Material1	Stainless Steel
Max Flow (GPM):	33
Max Head (Ft):	29
Max Pressure (PSI):	145
Phase:	1
RPM:	3380
Temperature Range (F):	36°-230°F
Type:	3-Speed Pump
Voltage	115v

Views: 11203
Model: 98961763
MPN: 98961763
Availability: In Stock
Usually ships: within 1 business day(s)
