1” Threaded Cast Iron Flo Check Valve

1” Threaded Cast Iron Flo Check Valve
1” Threaded Cast Iron Flo Check Valve QR Code
Views: 5738 Model: 220-6
UPC: 687752212068

MPN: 220-6


Weight:3.00 lb

Dimensions (L x W x H ): 6.00 x 5.00 x 3.00

Usually ships: 1 business days
Qty: Add to Cart


Have any questions?
Contact us at 1-800-246-9552

The 220-6 from Taco is a 1” Threaded Cast Iron Flo Check Valve. It's designed for use in hot water heating systems to prevent gravity circulation when the boiler is operating, but the space heating zone is not wanted. Taco Flo-Check allows to use the heating boiler for domestic hot water throughout the whole year. In systems with multiple circulator zones, Flo-Cheks allow heat to flow only into the zones that are calling for heat. Also, the thumb screw can be manually opened for gravity feed applications if the main circulator stops operating.

Technical Specifications:

  • Maximum Operating Pressure: 125 PSI (862 kPa)
  • Maximum Operating Temperature: 277°F (136°C)
  • Media: Water or Water + Glycol.
Product Specs
Size: 1"
