8" x 8" Steel Fire Rated Access Door
Click Image for Gallery
(Disc.)8"X 8" Fire Rated..
Technical Specifications:
Features:
Technical Specifications:
- Fire rating: UL (USA) 1.5 hours ("B" label); ULC (Canada): 2 hours
- Door and frame material: 16 gauge galvanized steel
- Door finish: prime coat suitable for painting
- Installation: Walls only
- Nominal door size (W x H): 8" x 8"
- Overall size (W x H): 10" x 10"
- Mounting Depth: 2-1/2"
- Rough Opening (W x H): 8-3/8" x 8-3/8"
Features:
- Self-closing, with heavy duty spring which assures positive latch
- UL rated for 1-1/2 hours ("B" Label) to ANSI-UL 10B in USA, and for 2 hours to CAN/ULC S104 in Canada - Wall Installations Only
- Concealed stainless steel pin hinge
- Recessed exterior latch is operated using a ring attached to the sliding bolt
- Frame is equipped with holes for both masonry anchors and screws/bolts, to facilitate installation in all types of wall construction
- Prime coated for easy paint application
| Product Specs | |
| Access door size | 8" x 8" |
- Views: 1900
-
- Model: FR8X8
- MPN: FR8X8
- Availability: Discontinued
- Usually ships: Upon availability
- $ 79.95
