UPS32-80/2 VersaFlo 3-Speed Cast Iron Circulator Pump, 115V
Click Image for Gallery
Grundfos UPS32-80/2 (alternative model number is UPS32-80F) is a VersaFlo series, commercial-grade cast iron 3-speed circulator pump with standard GF15/26 flanged connections, intended for heating and cooling applications.
Technical Specifications:
Features:
Technical Specifications:
- Casing: Cast Iron
- Circulator Pump Type: 3-Speed
- Connections: Flanged (GF15/26)
- Circulator Height (Flange to Flange): 11"
- Electrical Specs: 115V, 60 Hz, 280W max, 2.66 Amps max; 400V Capacitor
- Head Range: 0-26.25 ft
- Flow Range: 0-67 GPM
- Operating Temperature Range: 14°F - 248°F
- Max Operating Pressure: 145 psi
- Sound Pressure Level: 40 dB
- Dimensions (Depth x Width x Height): 12.12" x 8.31" x 11.00"
- Weight (lbs): 44.15 lbs
Features:
- 3-speed switch (Lo/Med/Hi) provides versatility for various applications
- Self-venting feature helps to prevent air locked circulator and eliminate unwanted noise
- Built-in thermal overload switch
- Whisper-quiet and maintenace-free operation
- Quick connectivity to terminals for easy installation
- Power LED indicator
- Lubricated bearings
- Suitable for up to pumping up to 50/50 glycol & water mix solution
- Impeller, bearing plate,and rotor are made of stainless steel
- Views: 136
-
- Model: UPS32-80/2
- MPN: 96402708
- Availability: In Stock
- Usually ships: within 1 business day(s)
- $ 1 055.95
