Frontier 107,000 BTU Steam Gas Boiler, Chimney Vent, 82.1% AFUE, Natural Gas
Click Image for Gallery
Note: product title indicates boiler''s Net AHRI (Net IBR) rating
Frontier boilers are a cost-effective and feature-rich solution for replacing most gas steam boilers on the market. They are fully packaged, low-profile (with built-in draft diverter) and use USA-made ASME cast iron heat exchanger - for a quick & easy installation & worry-free performance.
An optional near boiler piping kit (part# 850095U) is available to further simplify installation.
Boiler includes: Integrated Draft Diverter, Automatic Damper (with quick-disconnect harness), Honeywell/Resideo Gas Valve, Honeywell PressureTrol Pressure Limit (w/ auto reset & adjustable differential), Hydrolevel CycleGard LWCO, UTEC Intermittent Pilot Ignition Control, 15 psi Relief Valve (Watts or Apollo brand), Water Level Gauge Glass w/ Valves, Steam Pressure Gauge, Blocked Vent Switch, Isolation Relay, Drain Valve, Fittings (see product photo for details) and more.
Technical Specifications:
Features:
Frontier boilers are a cost-effective and feature-rich solution for replacing most gas steam boilers on the market. They are fully packaged, low-profile (with built-in draft diverter) and use USA-made ASME cast iron heat exchanger - for a quick & easy installation & worry-free performance.
An optional near boiler piping kit (part# 850095U) is available to further simplify installation.
Boiler includes: Integrated Draft Diverter, Automatic Damper (with quick-disconnect harness), Honeywell/Resideo Gas Valve, Honeywell PressureTrol Pressure Limit (w/ auto reset & adjustable differential), Hydrolevel CycleGard LWCO, UTEC Intermittent Pilot Ignition Control, 15 psi Relief Valve (Watts or Apollo brand), Water Level Gauge Glass w/ Valves, Steam Pressure Gauge, Blocked Vent Switch, Isolation Relay, Drain Valve, Fittings (see product photo for details) and more.
Technical Specifications:
- Input (BTU): 172,000
- Net AHRI Rating (BTU): 107,000
- DOE Heating Capacity (BTU): 142,000
- Efficiency (AFUE): 82.1%
- Fuel Type: Natural Gas (can be converted to propane with 112012-01 kit)
- Steam Sq. Ft.: 446 sqft
- Boiler/System Type: Steam Cast Iron Gas Boiler
- Boiler Connections: 2" NPT - Supply/Return Connections, 3/4" NPT - Relief Valve, 3/4" NPT - Drain, 1/2" NPT - Gas
- Relief Valve Setting: 15 psi
- Vent Type: Chimney Vent
- Vent Pipe Size: 6" (standard Cat I galvanized chimney vent pipe)
- Dimensions: 23" Wide x 28" Deep x 41" High
- Weight: 555 lbs (approx shipping weight)
Features:
- Low-profile design with built-in draft diverter, fits in low places
- Fully packaged and assembled
- Assembled in Pennsylvania with USA-made components, including robust, time-tested and efficient cast iron heat exchanger with metal section connections for increased boiler life
- Configurable for return connections on both sides
| Product Specs | |
| Boiler Sections | 6 |
| Boiler Vent Type | Chimney Vent |
| Fuel Type | Natural Gas |
| Input BTU Rating | 150,000 - 175,000 |
| Net BTU Rating | 100,000 - 125,000 |
| Efficiency (AFUE) | 82% |
| Product Type | Cast Iron Steam Boilers |
| Venting Size | 6" |
- Views: 886
-
- Model: FTR-6-172A-NHP
- MPN: FTR-6-172A-NHP
- Availability: In Stock
- Usually ships: within 1 business day(s)
- $ 2 780.00
