OS-200 Wireless Outdoor Sensor Kit for HydroStat 3200-Plus and 3250-Plus
Click Image for Gallery
Hydrolevel OS-200 is a wireless outdoor sensor kit, designed to monitor outdoor temperature to adjust the boiler water temperature. It overrides the Thermal Targeting feature on HydroStats, and uses a reset ratio method to control the boiler temperature, determining how much the boiler temprature is adjusted for changes in outdoor temperature. Works only with HydroStats 3200-Plus and 3250-Plus.
Technical Specifications:
Features:
Technical Specifications:
- Transmitter Rate: every 10 minutes
- Indoor Range: 8 walls / 250 ft
- Open Range: 5,000 ft (1,500 m)
- Temperature Range: -40°F to 140°F
Features:
- Enables outdoor reset feature on HydroStat 3200-Plus, 3250-Plus and 4200 HydroStat-IC models
- Updates displayed temperature every 10 minutes
- Warm Weather Shutdown - prevents the boiler from heating when the outside temperature reaches a set level
- Reset Ratio - regulates boiler's temperature in accordance to the outside temperature with a 20 degree differential for burner operation
- Thermal Boost - the control will continuously boost the reset temperature by 10 degrees every 30 minutes until thermostat is satisfied, reverting back to normal operation.
- Removable front access cover for easy wiring
- Green "Link" indicator displayed on the control indicates that transmitter and receiver are properly connected for data transfer
- Receiver panel indicates power, communication, and battery statuses
- The link button on the receiver can be used as a system reset
- Long battery life (minimum 10 years)
