UPS26-99SFC 3-Speed Stainless Steel Circulator Pump w/ IFC, 230V
Click Image for Gallery
Grundfos UPS26-99SFC is a 230V 3-speed stainless steel circulator pump with check valve - for closed and open-loop heating and cooling applications, as well as domestic hot water (DHW) systems.
Technical Specifications:
Features:
Technical Specifications:
- Casing: Stainless Steel
- Circulator Pump Type: 3-Speed
- Connections: Flanged (GF15/26)
- Circulator Height (Flange to Flange): 6-1/2"
- Electrical Specs: 230V, 60 Hz, 196W max, 0.9 Amps max; 400V Capacitor
- Head Range: 0-28.87 ft
- Flow Range: 0-33 GPM
- Operating Temperature Range: 36°F - 230°F
- Max Operating Pressure: 145 psi
- Sound Pressure Level: 40 dB
- Dimensions (Depth x Width x Height): 5.98" x 5.20" x 6.54"
- Weight (lbs): 10.17 lbs
Features:
- 3-speed switch (Lo/Med/Hi) provides versatility for various applications
- Includes integral check valve
- Whisper-quiet and maintenace-free operation
- Quick connectivity to terminals for easy installation
- Power LED indicator
- Lubricated bearings
- Suitable for up to pumping up to 50/50 glycol & water mix solution
- Made in the USA
- cULus Listed; NSF/ANSI 61 Listed
