1" Union Press Mixing Valve (Lead-Free), 95-131F
Click Image for Gallery
1" Union Press Mixing Valve (Lead-Free), 95-131F
Technical Specifications:
- System connections: 1" Press
- Output (mixing) temperature range: 95-131F
- Hot inlet temperature range: 120-185F
- Cold inlet temperature range: 39-80F
- Operating pressure range: 30-150 psi
- Min. temperature differential (betw. hot supply and mixing outlet): 20F
- Max. inlet pressure ratio (cold/hot supply): 2:1
- Min. flow rate: 0.5 GPM
- CV: 2.5
- Dimensions (H x W): 6.00" x 7.06"
- Approvals: NSFANSI 16 & 372, CSA B125.3, ASSE 1017
- Materials of construction: lead-free brass body, EPDM O-rings, st. steel springs, plastic handle.
Features:
- 1" Union Press Mixing Valve (Lead-Free), 95-131F
- Union connections simplify installation
- For low-temperature hydronic or hot/cold water plumbing systems
- Easy to set temperature-locking handle
- Lead-free, approved for potable water use.
- Views: 906
-
- Model: 78204W
- MPN: 78204W
- Availability: Discontinued
- Usually ships: Upon availability
- $ 97.95
