20" x 36" Hydronic Panel Radiator w/ Brackets, Model 11
NOTE: a pair of pipe adapters are required to connect supply and return piping to the radiator and are sold separately (use part# 551016844 for 1/2" copper pipe, 551646850 for 1/2" PEX or PEX-AL-PEX, 551646851 for 5/8" PEX or PEX-AL-PEX).
Features:
- Radiator includes mounting brackets w/ hardware, air vent (manual bleeder style), (2) drain plugs and thermostatic valve body with manual cap
- Powder coated white finish is highly resistant to scratching and can be painted
- Compatible with all piping configurations - parallel, series and dedicated
- Combines convection with radiant heat to offer better efficiency than baseboard and higher level of comfort
- Compact design means lower footprint
- Wide operating temperature range (120-180F) ensures compatibility with virtually all types and combinations of hot water heating systems
- Quiet - no screeching or hissing common with baseboards and steam radiators
Technical Specifications:
- Dimensions (H x L x D): 20" x 36" x 2-3/4"
- BTU Output @120°F: 1,140
- BTU Output @140°F: 1,824
- BTU Output @160°F: 2,560
- BTU Output @180°F: 3,311
- Water Content (Gal): 0.66
- Max Operating Pressure: 145 psi
- Max Operating Temperature: 200°F
Warranty:
- 10 years
| Panel Radiators | |
| BTU @ 120F | 1,000 - 1,499 |
| BTU @ 140F | 1,500 - 1,999 |
| BTU @ 160F | 2,000 - 2,999 |
| BTU @ 180F | 3,000 - 3,999 |
| Depth | 2-3/4" |
| Height | 20" |
| Length | 36" |
| Series | 11 |
- Views: 4470
-
- Model: BM-11-20X36
- MPN: BM-11-20X36
- Availability: Out Of Stock
- Usually ships: within 1 business day(s)
- $ 250.95
